HDR: Not Just for Other People

If you’ve ever done landscape photography, then you know the situation where your sensor’s dynamic range isn’t big enough for the dynamic range of the scene. In plain English: you can only get detail in the dark tones if you’re willing to sacrifice it in the light tones—in other words, to accept a washed-out sky—or vice versa: detailed bright tones at the cost of dark tones that all blend into pure black. There’s a solution: HDR.

There are multiple ways to grapple with a large difference between the bright and dark tones in a scene. Some photographers use gradient filters, but those can be fairly expensive, are easily scratched, and can be frustrating to work with. (The Cokin system is a major offender here.) The other option is to make use of HDR. And that’s the subject of this article.

What’s HDR? How Do I Do It?

HDR is short for High Dynamic Range. HDR pictures are created by combining (typically) three pictures, with one of them underexposed enough to preserve detail in the light tones, one overexposed enough to preserve detail in the dark tones, and the third one exposed “correctly”—i.e. in the middle. These three pictures are then combined into one picture that, as a result, is fully detailed throughout. For me personally, the following approach has proved itself in practice, and I can recommend it to you with a clean conscience:

1. Place your camera on a tripod!
2. Use your camera’s bracketing function (so that it takes multiple pictures with different exposures). Usually you’ll be able to set the amount of difference in EV between shots—that is, how much darker or lighter each one will be. Since you want three exposures, your settings may look like this: first picture with a middle exposure, the next one at +1 EV, and the last one at -1 EV.

Note: As for the settings on your particular camera, I’ll have to ask you to consult your camera’s manual—every brand and even every camera has different ways to adjust settings.

The three source pictures, with varying exposure values

The three source pictures, with varying exposure values

3. So—the ideal route is to take three pictures with differing exposures. Personally, I use a combination of bracketing and a self-timer. Why? With this combination, one press of the camera trigger gives me a delay set by the self-timer, and then three shots taken right after each other.

If I had to press the trigger three times myself, I might jostle the camera, and then the shots wouldn’t line up perfectly against each other. I could also solve this with a remote trigger of course, but this route is more elegant and effective, and doesn’t demand an extra investment. If you’ll be using long exposures or long lenses, and your camera offers a mirror lock-up function, then go with that as well. It will save you from camera shake, and save your pictures from blurring.

Note: Don’t forget to turn off image stabilization. This is because, if you have your camera on a tripod, then stabilization can actually make your pictures blurrier, not sharper. Also, on my Nikon with its 18–105 lens for example, stabilization makes my photos “shifted.” As if someone moved the tripod between each shot. And that’s a huge problem for HDR.

So—you’ve done all this, and now you have three pictures at different exposures, your camera was stable because it was on a tripod, and thanks to bracketing and a self-timer, you didn’t have to touch it during the shots. What Now? If you’ve stuck to the approach above, then what follows will be pleasant and easy work. For this reason alone, you shouldn’t head out to take source photos for HDR without a tripod in tow.

Creating HDR in Zoner Photo Studio

Start Zoner Photo Studio and, in the Manager module (the one Zoner starts up in), select your three source pictures in the Browser listing.. If you shoot to RAW (which I can only recommend), then convert your RAWs to TIFFs and use the TIFFs. Develop the RAWs straight, untouched. Just take care to ensure that the white balance is the same on all three photos.

Then in Zoner’s Create menu, use HDR via Exposure Blending. This displays the exposure-blending HDR wizard. That wizard’s first step shows all currently selected pictures. If no pictures are selected, then it shows every picture in the current folder. You can actually wait until here to make your selection, but personally I prefer to do it in the Browser.

In the next step, check to make sure the source photos are in the correct order—underexposed, correctly exposed, overexposed

In the next step, check to make sure the source photos are in the correct order—underexposed, correctly exposed, overexposed

In the step after that, align the photos. If you followed the advice above and took your pictures from a tripod, then Zoner will note that the source photos do not need alignment

In the step after that, align the photos. If you followed the advice above and took your pictures from a tripod, then Zoner will note that the source photos do not need alignment

I’ll just add here that, if I know I’ve used a tripod, I turn off image alignment even when Zoner doesn’t think my pictures are aligned. I do this because in theory, Zoner could try to “align what’s already been aligned” and end up shifting the source pictures. (This happened to me once.) In any case, if you use a tripod, then alignment is completely unnecessary.

After you click Next here, the real HDR alchemy begins. For this step, if you’re expecting concrete advice, then I’m afraid I have to disappoint you. Every picture is different, so this work demands trial and error and cautious work until you get the result you’re looking for

After you click Next here, the real HDR alchemy begins. For this step, if you’re expecting concrete advice, then I’m afraid I have to disappoint you. Every picture is different, so this work demands trial and error and cautious work until you get the result you’re looking for

But I suppose I should give at least some advice. Do be careful with the Mask blurring and Transition smoothness settings. Used carelessly, they can make a picture look unnatural by adding, for example, dark artefacts. My other advice is to avoid changing the contrast here.

Wrapping It All Up

At this stage the picture may still not quite match your expectations. That’s fine, as long as it’s correctly exposed, with no loss of detail in the dark or light tones. Also—since you’re a photographer, not a painter—make sure that your result still looks like a photograph, and not a page from a coloring book!

Once you’re satisfied with your settings in HDR via Exposure Blending, click Next and, if your picture is not perfect yet, go on and make a few minor edits in the Editor (using Open in Editor).

HDR makes most pictures lose some contrast, and so I make some cautious use of edits to the Tone Curve. The classic “S-curve” is an easy fit here. Then as needed I add a little saturation and vibrance

HDR makes most pictures lose some contrast, and so I make some cautious use of edits to the Tone Curve. The classic “S-curve” is an easy fit here. Then as needed I add a little saturation and vibrance

The final HDR picture after edits in the Editor

The final HDR picture after edits in the Editor

For comparison, before my edits in the Editor, the HDR image looked like this

For comparison, before my edits in the Editor, the HDR image looked like this

Compare the last two pictures, and you’ll clearly see that the HDR wizard is not the last step in great HDR. Only with post-editing does an HDR image really get its final “shine.”

Last updated 25. June 2014

0 0
Thank you! Please share this article too, so that it can also help other people.

Author: Jakub

Comments

  • Mike Sample

    I am curious about the justification for converting RAW image files to TIFF before performing the HDR exposure blending. Is that to improve the results, or possibly reduce computer resource requirements during the blending?

    • Zoner

      Thanks for very interesting question. Simply said, in ZPS 18, there is no need to convert RAW files at all, the program works with the full resolution (through the whole environment) and even with the edits you do in Develop module.
      But this post was written for version 16. And in this version (and maybe in 17 − depending on the settings) HDR function worked only with a lower quality preview. So it was the best option to convert your RAWs into high quality format.
      Hope this made it clearer for you.

  • Mike Sample

    The facts conveyed in this article are on target. I feel most readers would have taken more away from the lesson if a better example was used by the author, making it easier to see the benefit. I would have used image taken indoors which included a window where the outside objects were brightly illuminated, or a scene such as Zion National Park in the Narrows where the photographer is surrounded by deeply shaded scenery, but the upper cliffs are brightly illuminated. The editor needs to help submitting authors with similar suggestions.

    • Zoner

      Thank you Mike for your feedback! It is probably not the best sample picture, you’re right. But it is also true that HDR technique is very ofted used for landscape photos and a good HDR should look quite natural. But thank you, we will sure think about updating this article.
