What’s So Great About RAW?

Have you ever wondered on Earth you should shoot to RAW files? After all, they’re huge, and they have to be developed on a PC before use. Today we’ll look at some areas where RAW has the upper hand.

From time to time you’ll hear that you should be using RAW instead of the regular JPEG format. The difference between them is that while JPEGs contain normal pictures that have been developed in-camera, RAW files contain only “raw” data—a record of the signals emitted by the sensor chip, which needs to be processed before it becomes a picture. In short, RAW is not an acronym; RAW means this is raw data.

One giant advantage of RAWs is that they contain more information than normal JPEG images, and so you can make major edits to RAW pictures during development without reducing their quality. And what’s more, in some cases RAW can even help you rescue a picture that would otherwise be too light or too dark to save.

Let’s take a look at a few examples of where RAW conversion (sometimes called RAW development) is advantageous.

Blowout

In my mind, this might be the biggest plus. When you are photographing a high-contrast scene, for example one with a bright sky, a JPEG output will often include a large area that all runs together into 100% white. Since there are no differences at all between the pixels in this area, there is nothing you can do with it. Darkening the picture will just make the all-white area all-gray. But for RAW files, darkening can often uncover detail that was never missing, just invisible:

The same photo in two files—JPEG and RAW—produced with a single press of the trigger. If I try to darken the sky (in this case by about 1.39 EV) in the JPEG, all I get is one large one-color blob. I can safely darken the RAW much more, although there too I eventually run into limits. Canon 5D Mark III, Canon EF 16-35/2.8 II, 1/125 s, F8.0, ISO 160, focus 27 mm

The same photo in two files—JPEG and RAW—produced with a single press of the trigger. If I try to darken the sky (in this case by about 1.39 EV) in the JPEG, all I get is one large one-color blob. I can safely darken the RAW much more, although there too I eventually run into limits.
Canon 5D Mark III, Canon EF 16-35/2.8 II, 1/125 s, F8.0, ISO 160, focus 27 mm

Even with RAW, there are limits to darkening. The exact limits vary from camera to camera. But generally you can darken by up to about 1 EV and still have a good-looking picture. So even if you used 1/100 s instead of 1/200 s, your picture will still probably be savable.

White Balance

This is another major RAW advantage. As unintuitive as it sounds, white balancing can also cause data loss. When you’re shooting to JPEG, this adjustment is made right in the camera, and if it’s made badly (manually by you, or automatically by the camera), any correction you make on your PC later will mean lost quality.

For RAW output, no in-camera white balancing is applied at all. The camera merely gives information on what settings the camera would use if it did apply white balancing. You can use them if you wish, or use different settings at your leisure.

Here’s an example of damage while fixing white balance:

JPEG and RAW with badly set white balance (top) and after correction on a PC to make the paper completely white (bottom). Canon 5D Mark III, Canon 24-70/2.8, 1.0 s, F18, ISO 200, focus 58 mm

JPEG and RAW with badly set white balance (top) and after correction on a PC to make the paper completely white (bottom).
Canon 5D Mark III, Canon 24-70/2.8, 1.0 s, F18, ISO 200, focus 58 mm

Even after correction, the JPEG’s colors are washed-out, reducing the photo’s impact. With the RAW there’s no problem; white balancing on a PC does not reduce its quality.

Control Over the Details

Let’s say you’ve accidentally shot a picture too dark, or with too wide a range of lights and shadows. In any case—a photo where part or all of it needs to be brightened.

Another photo shot to JPEG and RAW, which we will be brightening by 4 EV. Canon 5D Mark III, Sigma 50/1.4 Art, 1/200 s, F10, ISO 400, focus 50 mm

Another photo shot to JPEG and RAW, which we will be brightening by 4 EV.
Canon 5D Mark III, Sigma 50/1.4 Art, 1/200 s, F10, ISO 400, focus 50 mm

This time for the results of the edit, I’m providing a complicated picture that will need some explanation:

The results of the brightening, in JPEG on the left and in RAW on the right.

The results of the brightening, in JPEG on the left and in RAW on the right.

The closeup of the brightened JPEG at the top left shows no noise, but it is blurry, even though I tried to turn off noise reduction. The RAW file, developed with standard settings and brightened (top right) does have noise, but it is considerably sharper. You can precisely choose how to balance noise reduction against sharpness… and you have the option of using different strengths for them in different parts of the picture. The final RAW-based picture can look e.g. like the one at the bottom right. (Unfortunately there is some red moiré here—perhaps a problem of this particular RAW conversion.) JPEGs can also be sharpened and de-noised, but you will be starting from less detailed data, and your edits will uncover the flaws of JPEG compression, so even your best efforts will probably contain unsettling digital noise (bottom left).

Editing at Top Quality

Technically speaking, this is just the previous point phrased differently. In the RAW format, colors are stored with greater precision, which today reaches up to 14 bits for each of the R, G, and B color channels, and so in theory a RAW picture can have for example up to 16,386 shades of green. JPEG pictures, meanwhile, work with 8 bits per channel, so for example just 256 shades of green. Any shades inbetween need to be rounded up or down.

If you make any major edits after that, this difference can become quite noticeable. Clouds are a classic example. They contain sufficient detail overall, but it’s in shades that are very close together, so you need to strongly increase contrast and do local sharpening:

As a side effect of sharply increasing the contrast, colors that were not discernable before have become visible. (In this case that’s not a problem.) Canon 5D Mark III, Canon 16-35/2.8 II, 1/250 s, F8, ISO 100, focus 33 mm

As a side effect of sharply increasing the contrast, colors that were not discernable before have become visible. (In this case that’s not a problem.)
Canon 5D Mark III, Canon 16-35/2.8 II, 1/250 s, F8, ISO 100, focus 33 mm

This detail shot shows the advantage of RAW over JPEG quite clearly:

A difference in the details.

A difference in the details.

Of course in both cases here we are now getting noise, which we can potentially remove. But notice here that processing the JPEG has also given us strips of a single color where the RAW still contains a smooth gradient.

Correcting Lens Defects

Some RAW converters contain sophisticated profiles for specific lenses (often in combination with a specific camera). You can use these profiles to make a converter automatically repair common defects, or to help with manual fine-tuning.

Here we should mention that you can do similar edits with JPEG files too. But as described above, you’ll be hurting the pictures’ quality, not to mention the fact that profiles for fully automatic edits are usually only available for RAW development tools.

JPEG on left; RAW with automatic correction on right. Close-ups: each picture’s bottom right corner.

JPEG on left; RAW with automatic correction on right. Close-ups: each picture’s bottom right corner.

In the illustration above, you can see corrections of three defects:

  • barrel distortion (note how the lines on the left are curved, not straight)
  • vignetting, i.e. darkening in the corners
  • chromatic aberration (look for the hints of violet and green on the left)

Some cameras can, at your request, make these corrections on their own. However, that removes your freedom to make more precise manual corrections—every individual lens has slightly different parameters, and so you might need slightly different edits.

RAW Also Brings Disadvantages

As with everything, RAW has both benefits and costs. In this case, the cost is that you always need to do at least a little PC processing, and so you can’t share your pictures immediately on, say, Facebook. RAWs’ file size—several times larger than normal—may also pose a problem for you. Last but not least, you need to use RAW development software. Zoner Photo Studio, with the DNG converter aiding RAW development is a great option here. But keep in mind that when you buy a new camera, its RAW files may not yet be supported by any converter at all—not even the DNG converter.

Despite all this, I fully recommend using RAW, and I recommend reaching for it whenever you want your photos to be the best they can be.

Last updated 3. December 2014

0 0
Thank you! Please share this article too, so that it can also help other people.

Author: Vit Kovalcik

I’ve been a freelancer since early 2012; photography is my living. I acquired my photography experience, both inside and outside the studio, during the previous years—when I was working all day and taking pictures every evening and weekend. I don’t have just one clearly defined topic; I like photographing people, but also cityscapes and landscapes.

Read All Articles.

Comments

  • Adrian Wood

    Who on earth would consider shooting in RAW just to post something on Facebook???

    • The photographers, I guess :) But anyway this was listed as a disadvantage – that you can’t easily share such photos on Facebook.

    • Stephen Bishop

      Set your camera to record RAW+JPG. Then delete which one you don’t need.

      • RAW+JPG is a waste of memory card space since the JPEG is already embedded in the RAW. A program like Photo Mechanic can just strip the JPEG from the RAW file.

        • Large size memory cards are so inexpensive these days that this is rarely a problem any more.

    • I do it all the time. Just because it’s on Facebook doesn’t mean it’s not worth editing and post-processing hence shooting in RAW.

  • Zakintosh

    The only issue for me is there is no support for SIGMA X3F Merrill RAW. It is the best quality of image, but it is not supported by DNG Converter nor Zoner PS, only by SIGMA Photo Pro which is a deeply appalling piece of slow code. If only SIGMA supported modern (not old) X3F format it would be a boon for any Foveon user out there.

  • Ken

    Being new to photography at the tender age of 76 i at first found Raw intimidating because of the need to edit. Now I have a handle on editing so am now confident to shoot in RAW. I found this article very interesting and as a novice very helpful for it gives me a better understanding of RAW.

    • Zoner

      We are happy to hear it, Ken, thank you!

  • Dave

    Very nice summary of RAW advantages. Since large image size is less of a problem nowadays due to cheap memory cards and disk storage, I prefer shooting in RAW where possible. 95% of my photos would do fine with JPEG, It’s those other 5% where RAW really shines and allows me to either save an otherwise unusable photo or make an ordinary photo outstanding. The only problem is I don’t know ahead of time which pictures will need the advantages of RAW processing – hence the desire to shoot everything in RAW.

  • Oscar Burd

    Very good article.

  • Danny

    Other than correcting lens defects, are there any advantages to using the RAW module over opening the raw image in the editor at full resolution?

    • Zoner

      Hi Danny, the RAW module – now called Develop in ZPS 18 – is designed for work with RAW, while the Editor is not. It is possible to open a RAW in the Editor and then save it to another format (you cannot save back to RAW), but there is usually no benefit to it, since Develop can do most of what the Editor can, and a couple of things it can’t. (Besides lens profiles, this includes the Color Shift filter.) Also, the controls are more streamlined towards RAW development – it’s less cluttered.

      If you want to work with selections, you will have to work in the Editor at some point, so for that special situation, there is something to be said for just taking the RAW straight to the Editor.

      Also note that Develop makes “non-destructive edits”, where your edits are stored in a special text file alongside the picture, and only applied during export. This lets you experiment heavily with a RAW without having to maintain multiple developed versions (or work from one version that will degrade a bit with each edit).
